Finder releases two new features for its Toolbox app, the app that lets you program Finder devices simply, using your smartphone.
In addition to a new, redesigned icon, the Finder Toolbox app <a href="https://www.findernet.com/en/worldwide/series/12-series-mechanical-or-electronic-digital-time-switches-16a/type/type-12b2-annual-astro-switch-with-bluetooth/" target="_blank" rel="noopener">now includes the Type 12.B2</a>, a recently launched annual Bluetooth astro time switch.
Using the app – compatible with both Android and iOS systems – the parameters of the compatible Finder devices can be managed quickly and intuitively with NFC (Near Field Communication) and Bluetooth 5 technology.
You can configure and/or read programs, and modify a wide range of options, according to your needs.
You can also save your program and to apply it to multiple devices, sharing them with other users if you wish.

In addition to the Type 12.B2 Bluetooth annual astro time switch, using the Finder Toolbox app you can also program other products within the Finder range. Here’s the complete list:
<ul>
<li>Type 12.B2: Bluetooth annual astro time switch, 2 contacts</li>
<li>Type 7M.24: Single-phase bi-directional energy meter with LCD display</li>
<li>Type 7M.38: Two-way multifunction energy meter 80 A</li>
<li>Type 70.51: Current monitoring relay</li>
<li>Type 12.51: Time switch, daily/weekly</li>
<li>Type 12.81: Digital astro time switch</li>
<li>Type 12.61: Digital weekly switch, 1 contact</li>
<li>Type 12.61: Digital weekly switch, 2 contacts</li>
<li>Type 12.A1: Weekly astro time switch, 1 contact</li>
<li>Type 12.A2: Weekly astro time switch, 2 contacts</li>
<li>Type 12.A4: Weekly astro time switch with PWM/0-10V analog output</li>
<li>Type 84.02: Multifunction SMARTimer with display, 2 contact</li>
</ul>

Finder products programmable with the Finder Toolbox app.

The Finder Toolbox Plus app, downloadable from <a href="https://play.google.com/store/apps/details?id=com.findernet.ToolboxNFC&amp;hl=en" target="_blank" rel="noopener">Android</a> and <a href="https://apps.apple.com/app/finder-toolbox-nfc/id1522529367" target="_blank" rel="noopener">iOS</a> stores, is still available to users who wish to program compatible Finder devices. However, to get the benefit of all the new features, we’d suggest using the new Finder Toolbox app.
<h4>To stay up-to-date with all the latest news about Finder-compatible apps, visit the <a href="https://www.findernet.com/en/worldwide/support/software-and-apps/" target="_blank" rel="noopener">Software and Apps section</a></h4>

Other Finder apps

Finder Toolbox, the app for programming Finder devices with a smartphone, has now got two new features.

Annual Astro Switch with Bluetooth Type 12.B2 with annual function, for scheduling over specified periods or specific days of the year.
Ideal for schools, small automations, public lighting and advertising.
Synchronizable via wireless GPS antenna (Type 012. BG.8.230) and expandable via Bluetooth inputs and outputs (Type 13.21-B and Type 1Y.P2).
Other technical features:
<ul>
<li>Different programming methods:
&#8211; “Smart” programming via Smartphone &#8211; Android and Apple &#8211; with Bluetooth and NFC technology
&#8211; “Classic” joystick manual programming</li>
<li>Annual programming with advanced functions</li>
<li>Bluetooth 5 + NFC for app configuration and expandability</li>
<li>2 CO (DPST) 16 A outputs on board</li>
<li>Supply voltage: 110…230 V AC/DC</li>
<li>Outputs and inputs expandable via 1Y.P2 and 13.21-B</li>
<li>Synchronization via external wireless GPS antenna (Type 012.BG.8.230)</li>
</ul>

Function and features:

Type 12.B2 - Annual Astro Switch with Bluetooth

The single-phase bi-directional energy meters with LCD display, Types 7M.24.8.230.0001, 7M.24.8.230.0010, 7M.24.8.230.0210 and 7M.24.8.230.0310 are the ideal products for monitoring domestic/industrial energy consumption, including applications in offices, photovoltaic systems and energy metering within campsites.
The Type 7M.24 energy meters are programmable via smartphone thanks to NFC technology, which allows you to read the measured energy even in the absence of a network.
They are also distinguished by the touch-sensitive navigation and programming key and by the power/control terminals with integral sealable tamperproof terminal shield.
Other features:
<ul>
<li>4 MID certified counters for imported and exported active and reactive energy</li>
<li>8 resettable counters for active, reactive, absolute apparent, imported and exported energy</li>
<li>Extensive real-time measurement capability: V, I, Pf, f, voltage and current THD and operating run-time for preventive maintenance activities</li>
<li>Communication protocols M-bus and Modbus RS485</li>
</ul>

Type 7M.24 - Bi-directional single-phase energy meter with LCD display

The 80A multi-function energy meters, Types 7M.38.8.400.0112, 7M.38.8.400.0212 and 7M.38.8.400.0312 are MID certified devices rated at 80 A, 70 °C and are for three-phase (3 or 4-wire) and single-phase systems. These meters are the ideal device for electric vehicle charging stations.
They are distinguished by the backlit matrix display, the multi-function touch key and the sealable tamperproof terminal shield.
They will display and store both total and partial (resettable) energy consumption, and display the following real-time values: V, A, PF, kW, kVA, kvar, Hz, THD V, THD A, phase angle and direction of power flow.
Type 7M.38 is available in the versions:
<ul>
<li>7M.38.8.400.0112 with double S0 pulse output for remote energy control and IR communication interface</li>
<li>7M.38.8.400.0212 with integrated Modbus RS485 and impulsive S0 communication port for remote energy control and IR communication interface</li>
<li>7M.38.8.400.0312 with integrated M-Bus and S0 impulsive communication port for remote energy control and IR communication interface</li>
</ul>
Other characteristics:
<ul>
<li>Direct connection up to 80 A, double tariff, double S0 pulse output</li>
<li>2 MID certified meters for active energy + 2 for reactive energy (national certification), 16 resettable meters</li>
<li>Active energy accuracy class: Class B according to EN 50470-3 (MID)</li>
<li>Reactive energy accuracy class: Class 2 according to EN 62053-23</li>
<li>Protection category II</li>
</ul>

Type 7M.38 - 80 A bi-directional multi-functional energy meter

Type 12.51 Digital (Analogue-style) time switches, 1 CO 16 A, with daily/weekly programming and two programming modes:
<ul>
<li>Classic via joystick</li>
<li>Smart via smartphone with NFC technology</li>
</ul>
Shortest programming interval of 30 minutes. Easily programmable in daily or weekly configuration
Features include:
<ul>
<li>Automatic summer/winter time change</li>
<li>Changeover 16 A</li>
<li>LCD display for viewing, configuration and programming</li>
<li>Block with 4-digit PIN</li>
<li>Backlit display</li>
<li>Internal battery for programming without power supply, easily replaceable</li>
<li>Separation between the power supply circuits and contacts</li>
<li>Width 35 mm</li>
<li>35 mm rail (EN 60715) mounting</li>
<li>Cadmium-free Contacts</li>
</ul>

Type 12.51 - Time/Astro-Switch 16A

Type 12.61 Digital Time switch allows for &#8220;weekly&#8221; programming. It can be programmed in “Classic” mode via the joystick, or “Smart” mode via smartphones with NFC communication.
1 CO 16 A output and functions: Switch ON, Switch OFF, Pulse
Features include:
<ul>
<li>1 CO 16 A output</li>
<li>Functions: Switch ON, Switch OFF, Pulse (1 s&#8230;59 min)</li>
<li>Minimum time interval setting &#8211; 1 minute</li>
<li>Summer/Winter &#8211; European, Australian, Brazilian time</li>
<li>LCD display for status indication, set-up and programming</li>
<li>Lock with a 4-digit PIN</li>
<li>Back-lit display</li>
<li>Internal battery for set-up and programming without supply, easily replaceable from the front</li>
<li>Protective separation between supply and contacts</li>
<li>35 mm rail (EN 60715) mount</li>
<li>Cadmium-free contact material</li>
</ul>

Type 12.61 - Digital time switch 16A

Type 12.81 Digital Astro Time switch can be programmed in “Classic” mode via the joystick, or “Smart” mode via smartphones with NFC communication. Astro program: calculation of sunrise and sunset times through date and location coordinates.
Option for Astro ON period override, by timeswitch.
Location coordinates easily settable for most European countries through post codes.
Offset function: allows programming of switching times offset from the astro time (by up to 90 min, in 10 min steps).
Features include:
• Automatic winter/summer time changeover
• 1 CO 16 A
• LCD display for status indication, set-up and programming
• Lock with a 4-digit PIN
• Back-lit display
• Internal battery for set-up and programming without supply, easily replaceable from the front
• Protective separation between supply and contacts
* 35 mm wide
• 35 mm rail (EN 60715) mount
• Cadmium-free contact material

Type 12.81 - Digital time Astro switch 16A

Type 12.A1 Weekly Astro time switches, 1 CO 16 A. ON/OFF and Pulse function.
Two programming modes:
<ul>
<li>Classic via joystick or Smart via smartphone with NFC technology</li>
<li>Astro program: calculation of sunrise and sunset times based on the date and geographical coordinates</li>
</ul>
Features include:
<ul>
<li>Functions: Astro ON, Astro OFF ON/OFF switching</li>
<li>Pulse function: 1 s… 59 min</li>
<li>Geographical coordinates (for ASTRO function) easily settable, or by post code for most European countries</li>
<li>Offset function: allows you to anticipate or delay (up to 90 min in 1 min steps) the switching off and on of the lights with respect to the sunrise and sunset times</li>
<li>Shortest progamming interval 1 minute</li>
<li>Automatic change of summer/winter time</li>
<li>LCD display for viewing, configuration and programming</li>
<li>Block with 4-digit PIN</li>
<li>Backlit display</li>
<li>Internal battery for programming without power supply &#8211; easily replaceable</li>
<li>Separation between the power supply circuits and contacts</li>
<li>Width 35 mm</li>
<li>35 mm rail (EN 60715) mounting</li>
<li>Cadmium-free Contacts</li>
</ul>

Type 12.A1 - Time/Astro-Switch 16A

Type 12.A2 Weekly Astro time switches, 2 CO 16 A. ON/OFF and Pulse function. Two programming modes:
&#8211; Classic via joystick or Smart via smartphone with NFC technology
&#8211; Astro program: calculation of sunrise and sunset times based on the date and geographical coordinates
Features include:
<ul>
<li>Functions: Astro ON, Astro OFF ON/OFF switching Pulse function: 1 s… 59 min</li>
<li>Geographical coordinates (for ASTRO function) easily settable, or by post code for most European countries</li>
<li>Offset function: allows you to anticipate or delay (up to 90 min in 1 min steps) the switching off and on of the lights with respect to the sunrise and sunset times</li>
<li>Shortest progamming interval 1 minute</li>
<li>Automatic change of summer/winter time</li>
<li>LCD display for viewing, configuration and programming</li>
<li>Block with 4-digit PIN • Backlit display</li>
<li>Internal battery for programming without power supply &#8211; easily replaceable</li>
<li>Separation between the power supply circuits and contacts</li>
<li>Width 35 mm</li>
<li>35 mm rail (EN 60715) mounting</li>
<li>Cadmium-free Contacts</li>
</ul>

Type 12.A2 - Time/Astro-Switch 16A

Type 12.A4  Weekly Astro time switch.
Suitable for applications where a variable light level is required &#8211; programmable via smartphone with NFC communications. Compatible with power supply/ballasts with 0-10V or PWM inputs.
Features include:
<ul>
<li>1 analog output: 0-10V or PWM</li>
<li>Functions: &#8220;Astro&#8221; ON, &#8220;Astro&#8221; OFF, ON/OFF</li>
<li>Location coordinates easily settable for most European countries through Post codes</li>
<li>Offest function: allows programming of switching times offset from the astronomic time (by up to 90 min, in 1 min step)</li>
<li>Minimum time interval setting &#8211; 1 minute</li>
<li>Summer/Winter European, Australian, Brazilian time</li>
<li>LCD status indication, set-up and programming</li>
<li>Lock with a 4-digit PIN</li>
<li>Back-light display</li>
<li>Internal battery for set-up and programming without supply, easily replaceable from the front</li>
<li>Protective separation between supply and contacts</li>
<li>35 mm wide</li>
<li>35 mm rail (EN 60715) mount</li>
<li>Cadmium free contact material</li>
</ul>

Type 12.A4 - Time/Astro-Switch 16A

Type 84.02 is a digital SMARTimer, multi-function with ‘2 in 1’ two channels programmable, totally independently, in a single product. It has two programming modes: ‘Smart’ mode via Smartphone with NFC technology or ‘Classic’ mode via integrated joystick.
This product has large backlit LCD display for easy parameter reading and it is flexible because of the possibility to create new specific functions, mixing the 30 functions available on each channel.
The large display allows for easy display of target time, partial time, timing indicator in progress, status of inputs, status of outputs.
Features include:
<ul>
<li>2 changeover contacts 16 A</li>
<li>Two supply voltages available:12 … 24 V AC/DC and 110 … 240 V AC/DC (non-polarized)</li>
<li>Great precision and possibility of choice for defining times:
• Scale settable in tenths of a second, seconds, minutes, hours
• Times settable from 1 tenth of a second to 9999 hours</li>
<li>Separate Start inputs for each channel; common reset input and common pause input (that can be enabled on each channel)</li>
<li>PIN that can be set to protect access to programming</li>
<li>Type of counting selectable ascending or descending</li>
<li>35 mm rail (EN 60715) mounting</li>
</ul>
Type 84.02.0.024.0000: possible direct interface with sensors of proximity (both PNP and NPN)

Function and features

Type 84.02 - SMARTimer 16A
